Introduction:
With the high technology of the separated pressurized solar system, Mideasolar company is famous in the solar scopes not only in China but also in oversea. The SSM/PBM/TCM series are the newly and latest improving quality type and tested to suitable for the coldest area, such as in the north of Europe, which we have exported to Norway, Netherlands, UK, Poland, etc. It is also widely used in the other western developed countries for domestic and engineering. These systems are suitable for the area with hard and saline water. It is easy to be utilized and welcomed by the customers not only old but also young.

Advantages
·Easy to install. The SMM/PBM/TCM series module comes easy to install by our part, such as tank, work station and complete module.
·More efficiency. The hot water in the pane will be transferred to the storage tank immediately through work station circulation.
·Easy to use. Hot water with pressure, it will comes hot water immediately when water cock opened.
·More comfortable. Act as the best function, who will realize what the real living life under the hot water bath.
·Proven reliability. Can operate for years without owner intervention or maintenance. They "just work", minimal maintenance.
·Compatible with existing water heater. The SMM/PBM/TCM series can be connected directly to your present water-heater thus converting it to a solar-assisted water-heater.
·Overheat protection. Through protection function, the high temperature hot water by-pass to protect the heat collecting module.
·Anti-freeze protection. No need to periodically flush and fill the system with expensive, new anti-freeze fluids. Through setup circulation, the heat collecting module will be protected in the coldest night.

Products feature:
☉      Installation size: 1.6M2(20pcs) /2.4M2(30pcs)
☉      Manifold material: aluminum zinc alloy steel.
☉      Manifold Dimension: 170mm.
☉      Support material: aluminum zinc alloy steel structure.
☉      Manifold insulation: puf 65 mm.
☉      Vacuum tube mode: Ф47-1500.
☉      Vacuum tube number: 20/30.
