Main Technical Date

1.       Dimension:210 mm x 145 mm x 40 mm

2.       Self power consumption: <3W

3.       Measuring accuracy of temperature: ±2℃

4.       Temperature range of measurement: 0~99℃

5.       Maximum power of controlled pump: ≤600W

6.       Power of accompanied electrical heating wire: ≤800W

7.       Power of auxiliary electrical booster ≤2000W (standard collocation), ≤3000W (not standard, selection available)

8.       Electromagnetic valve parameter: DC 12V,AC 220V, pressurized valve and un-pressurized valve are available for selection

＊     operation pressure of pressurized valve: 0.02Mpa~0.8Mpa,suitable for providing water directly

＊     operation pressure of un-pressurized valve: 0.0Mpa,connected with water tank or low pressure water providing

Main functions

1.       Water temperature display

2.       Water level display

3.       Water level pre-setup

4.       Manual water loading

5.       Temperature controlled water loading

6.       Timing water loading

7.       Water loading when tank is lack of water

8.       Compulsive water loading

9.       Increasing water pressure during water is loaded

10.   Water temperature pre-setup

11.   Manual heating

12.   Timing heating

13.   Hot water circulation

14.   Hot water pipe insulation

15.   Low pressure protection

16.   Collector tube protection

Error code

1.       ERROR0 E0 Sensor cable damaged

2.       ERROR4 E4 High temperature protection of collector pipe

3.       ERROR6 E6 Error of temperature sensor
