Main Technical Date

1.       Dimension:210 mm x 145 mm x 40 mm

2.       Self power consumption: <3W

3.       Measuring accuracy of temperature: ±2℃

4.       Temperature range of measurement: 0~99℃

5.       Maximum power of controlled pump: ≤600W

6.       Power of accompanied electrical heating wire: ≤800W

7.       Power of auxiliary electrical booster ≤2000W (standard collocation), ≤3000W (not standard, selection available)

8.       Electromagnetic valve parameter: DC 12V,AC 220V, pressurized valve and un-pressurized valve are available for selection

＊     operation pressure of pressurized valve: 0.02Mpa~0.8Mpa,suitable for providing water directly

＊     operation pressure of un-pressurized valve: 0.0Mpa,connected with water tank or low pressure water providing

Main functions

1.       Time display

2.       Water temperature display

3.       Water level display

4.       Auto mode

5.       Water level pre-setup

6.       Manual water loading

7.       Temperature controlled water loading

8.       Timing water loading

9.       Water loading when tank is lack of water

10.   Compulsive water loading

11.   Increasing water pressure during water is loaded

12.   Manual heating

13.   Timing heating

14.   Hot water circulation

15.   Hot water pipe insulation

16.   Low pressure protection

17.   Collector tube protection

18.   Memory protection when power if failure

Error code

1.       ERROR0 E0 Sensor cable damaged

2.       ERROR4 E4 High temperature protection of collector pipe

3.       ERROR6 E6 Error of temperature sensor
